Spanish tile roll forming machine
Spanish tile roll forming machine
The Spanish tile roll forming machine is a specialized industrial system designed to produce metal roofing tiles with a distinctive stepped profile. Its core function is to transform flat metal coils (like steel or aluminum) into finished, three-dimensional roofing sheets that offer the classic look of tiles combined with the durability of modern metal .
Spanish tile roll forming machine
Function of Spanish tile roll forming machine
The Spanish tile roll forming machine is a specialized industrial system designed to produce metal roofing tiles with a distinctive stepped profile. Its core function is to transform flat metal coils (like steel or aluminum) into finished, three-dimensional roofing sheets that offer the classic look of tiles combined with the durability of modern metal.
Technical data of Step tile roll forming machine
| Parameter | Typical Specification | Details / Notes |
| Material Thickness | 0.4 mm – 0.6mm | Suitable for PPGI, aluminum coils, or color steel coils |
| Forming Stations | 17 stations | Number of roller pairs that gradually shape the metal |
| Shaft Diameter | Φ72 mm | Made of high-grade 45# steel, precision-ground |
| Roller Material | 45# Forged Steel, Chrome Plated | Chrome plating (approx. 0.05mm) ensures smooth operation and corrosion resistance |
| Forming Speed | About 6 m/min | Standard speed is 5-6m/min |
| Cutting Blade | Cr12MoV, Heat Treated | High-hardness material (58-60HRC) for long blade life and clean cuts |
| Cutting Tolerance | ±1mm | Precision of the finished sheet length |
| Control System | Mitsubishi PLC with Touch Screen | Allows for automatic control of length, quantity, and batch settings |
RFQ
1. Why Use Spanish Tile Roll Forming Machine?
Investing in a Spanish tile roll forming machine offers several practical advantages for manufacturers and builders:
High Production Efficiency: It enables the rapid production of large quantities of tiles, significantly reducing project lead times.
Design Flexibility: Modern machines are highly customizable. Manufacturers can produce precise profiles based on customer technical drawings, adapting to local market preferences and building codes.
Cost-Effectiveness: By automating production, it reduces labor costs and minimizes material waste. The resulting tiles are also lightweight, which can lower transportation and structural support costs.
Durability and Performance: The tiles are corrosion-resistant, weatherproof, and have a long lifespan (e.g., 40+ years for aluminum). They are also suitable for various applications, including post-disaster reconstruction and green building projects due to aluminum’s recyclability.
In summary, the Spanish tile roll forming machine efficiently automates the production of durable, stylish, and highly customizable metal roofing tiles, offering a versatile solution for modern construction needs.
